Bend-Tech PRO Update

Bend-Tech PRO – Upgrade (Release 7.x)

Upgrading to Bend-Tech Pro will to have access to:

  • New Interfaces – Sketch 2D/3D, Harpoon 3D
  • Improved Assembly Cutting
  • Easier PickPoint Creation
  • More flexible Part Creation in Assembly
  • Improve Template interface
  • Cleaner, easier to use interface
  • Large Radius module available for PRO
  • Improved single part interfaces
  • Many new additional features

You must own and have registered Bend-Tech PRO 3.x, 4.x, 5.x or 6.x for this purchase.

$115.00

Description

Bend-Tech PRO 7x Upgrade

New 7x features:

  • New Interfaces – Sketch 2D/3D, Harpoon 3D
  • Improved Assembly Cutting
  • Easier PickPoint Creation
  • More flexible Part Creation in Assembly
  • Improve Template interface
  • Cleaner, easier-to-use interface
  • Large Radius module available for PRO
  • Improved single-part interfaces
  • Many new additional features.

Both CD and Download will be provided with this purchase. (A download link will be sent to your email within 2-5 hours during normal business hours.)
