EZ3D to EZ3D 7.x

Bend-Tech EZ-3D 7x Upgrade

New features of EZ3d include:

  • New Interfaces – Sketch 2D/3D, Harpoon 3D
  • Improve Template interface
  • Add Rotation to Templates
  • Cleaner, easier to use interface
  • Improved single part interfaces
  • Many new additional features.

$80.00

Description

New 7x features:

  • New Interfaces – Sketch 2D/3D, Harpoon 3D
  • Improve Template interface
  • Add Rotation to Templates
  • Cleaner, easier to use interface
  • Improved single part interfaces
  • Many new additional features.

Both CD and Download will be provided with this purchase. (Download link will be sent to your email within 2-5 hours on normal business hours.)
