EZ3D to PRO

Bend-Tech PRO (Upgrade from EZ3D)

Bend-Tech PRO will allow you to:

  • Full 3D assembly design
  • Complete dimensioning
  • Cutting instructions including fish-mouthing

$175.00

Description

Bend-Tech PRO (Upgrade from EZ3D)

Bend-Tech PRO was introduced with our assembly interface which has taken the market by storm. At a modest price, everyone can design and fabricate tubing like the pros.

We spent countless hours observing and asking questions to our customers about how they would like to see PRO work. Our customers wanted the power but didn’t want the learning curve and frustration that comes with a standard CAD system. We peeled back the pillars of standard CAD thinking and put together an interface that is logical beyond belief. Most customers are comfortable with full assembly design in less than 2 hours. Again don’t let the learning curve fool you, customers are designing entire fabricated tube chassis the first night they sit down with the software.

The assembly interface consists of 3 primary functions.

  • Full 3D assembly design
  • Complete dimensioning
  • Cutting instructions including fish-mouthing



At any time during the design in PRO’s assembly interface, you can look up the details of a part and print out entire manufacturing instructions. PRO uses your tooling and materials libraries so you are confident you can create what is being designed.

Bend-Tech PRO will allow your creativity to become reality. PRO has empowered the fabricator. PRO allows any fabricator to become proficient in tubing manufacturing in a few short hours. If you are a serious hobbyist, start-up shop, or a small full-time fabricator, PRO will save you thousands of dollars in costly rework and material scrap.

Download link will be provided via email with this purchase. (If you do not receive your download email within 30 minutes, check your spam folder.)
